Bootlace Ferrule 2.5mm² X 8mm Pin Grey
Features
- Prevents wire fraying and strand separation
- Color-coded grey for quick 2.5mm² conductor identification
- Halogen-free Polyamide 6.6 insulation rated for -30 °C to +105 °C
Where to use it
Bootlace terminals provide a clean and secure termination for stranded wires, preventing fraying and ensuring reliable insertion into terminal blocks or screw connectors. Designed to terminate flexible cables, they are ideal for general wiring in control panels, switchboards, solar systems, and automotive DC setups where wires are frequently handled or repositioned.
Product Dimensions
- Conductor Size: 2.5 mm²
- Pin Length (L3 / Depth): 8 mm
- Total Length (L): 14 mm
- Stripping Length (L2): 6 mm
- Inner Diameter (D2): 2.2 mm
- Outer Diameter (D): 4.2 mm
Safety Features
- Polyamide 6.6 insulating collar prevents accidental short circuits
- Secure strain relief reduces mechanical stress on conductor strands
Applications
4WD
RV's
Caravans
Off-Grid Systems
Tiny Houses
