Alvolta 40A 12/24V PWM Solar Controller
Alvolta 40A 12/24V PWM Solar Controller
PWM features
- Pulse Width Modulation (PWM) Technology
- 40 A rated charge current
- Maximum solar input voltage of 55Voc
- 3-Stage charging algorithm
- Integrated temperature compensation
- Negatively grounded
- Suitable for 12/24 V systems
Unit features
- Die-cast aluminium casing
- Backlit LCD display screen
- LED status indicators
- Built-in Bluetooth
Compatible battery chemistries
- Lithium
- Flooded
- Sealed lead acid
- GEL
Where to use it
Designed to harness and optimise the power generated by your solar panels, this PWM solar controller maximises solar energy delivery to your battery using advanced Pulse Width Modulation (PWM) technology. It adjusts charging rates depending on your battery's state, ensuring optimum efficiency and maintaining your battery's health and longevity.
Ideal for 4WDs, small RVs, caravans, camper trailers, and minor battery trickle-charging needs. It is particularly well-suited to systems where the solar panel nominal voltage matches the 12V or 24V battery bank (e.g., a 12V panel charging a 12V deep cycle battery).
Dimensions
Width | 159 mm |
Height | 118 mm |
Depth | 59 mm |
Weight | 0.65 kg |
Warranty
- 3-year warranty
Applications
Marine
RV's
Caravans
Off-Grid Systems
Tiny Houses
Cabins
About Alvolta
Australian-owned and operated and driven by a passion for excellence, Alvolta offers unwavering performance and durability even in harsh Australian conditions. Alvolta specialises in precision-engineered DC components, designed to enhance off-grid adventures. Their commitment to delivering superior power performance with uncompromising quality is evident in their lineup of solar panels, solar charge controllers, circuit protection devices, mounting solutions, tools, and more. Supply yourself with all the arsenal you need to extend your power supply and adventure for longer with Alvolta.
