High visibility ON/OFF indication; padlockable handle (6mm shackle)
Base mounted mechanism for easier termination and more wiring room
Build
IP66, UV resistant, anti-corrosive grey enclosure
4 x M25 conduit entries, top and bottom
4 screws for high strength locking
IEC 60947-3 AC-22A; SAA, RCM and CE approved
Where to use it
The BYA-63 63A isolates air conditioners, pumps, solar inverters and other outdoor equipment, with a locked-rotor "M" rating to AS 3133 for motor loads.
Installed by a licensed electrician. Mains cable up to 25mm², neutral and earth up to 16mm².
Dimensions
Width
89 mm
Height
168.8 mm
Depth
87.3 mm
Warranty
Manufacturer's warranty
Applications
4WD
RV's
Caravans
Off-Grid Systems
Tiny Houses
Cabins
About ZJ Beny
ZJ Beny (Zhejiang Benyi Electrical) makes DC protection and switching gear for solar PV and battery storage: DC isolators, miniature and moulded case circuit breakers, AC isolators and enclosures, tested to IEC and AS standards with SAA approval.
It lets you safely disconnect a circuit, such as the AC output of a solar inverter, so the equipment can be serviced or shut down in an emergency. It must be installed by a licensed electrician.
Yes. The handle is pad-lockable and takes a padlock with a shackle of up to 6 mm, so the circuit can be locked off while work is carried out.
Yes. The enclosure is rated IP66 and is UV resistant. Use suitable M25 conduit fittings or cable glands on the entries so the seal and rating are maintained.
Single-pole (250 V) models suit single-phase circuits. Three-pole (440 V) models are for three-phase circuits, such as a three-phase inverter output.
AC-22A is an IEC 60947-3 utilisation category for switching mixed resistive and inductive loads, including moderate overloads. It is not a motor-switching (AC-23A) rating.
