Victron Lynx Class-T Power In (M10)
Lynx busbar module with two Class T fuse holders for up to two lithium battery strings, 1000 A
Victron Lynx Class-T Power In (M10)
Features
- Connects and fuses up to two lithium battery strings
- Two Class T fuse holders (fuses sold separately: 225, 250, 350 or 400 A)
- Positive and negative busbars with M10 connections
- 1000 A continuous rating, 9 - 60 V DC
- Ground connection for the DC system
- Part of the Victron Lynx modular busbar system
- Protective ABS cover
Where to use it
The Lynx Class-T Power In is the starting point of a Lynx DC system in larger lithium installations: off-grid homes, boats, motorhomes and trucks with high-current inverters.
It gives each of up to two battery strings its own fast-acting Class T fuse, and bolts straight onto other M10 Lynx modules such as the Lynx Distributor or Lynx Smart BMS. For three or more strings, use more than one module.
Dimensions
| Height | 279 mm |
| Width | 169 mm |
| Depth | 97 mm |
| Weight | 2.1 kg |
Warranty
- 5-year warranty
- Access to Springers Solar's warranty support team
- Authorised Victron dealer
Applications
Marine
RV's
Caravans
Off-Grid Systems
Tiny Houses
Cabins
More about Victron:
Victron Energy has a strong, unrivalled reputation for technical innovation, reliability, and build quality. Their products are widely considered to be a professional choice for independent electric power. Efficiently combining two or more distinct power sources is what they do best. Their products include sinewave inverters, sinewave inverters/chargers, battery chargers, DC/DC converters, transfer switches, battery monitors and more.
