HellermannTyton Bellmouth Cable Lug 95mm² x 10mm Stud (5)
Lug features
Bellmouth copper cable lug for 95mm² cable, M10 stud
Bellmouth (flared) barrel entry for fine-stranded flexible cable
Supplied in a pack of 5
Build
High-conductivity copper, tin plated
Operating temperature -55°C to +155°C
RoHS compliant; suits HellermannTyton crimp tools
Where to use it
The CL95-10BM terminates 95mm² copper cable onto an M10 stud, for battery, inverter, busbar, isolator and switchboard connections in solar, off-grid, automotive, marine and industrial installs.
Crimp with a hexagonal crimp tool sized for 95mm² cable and cover the barrel with heat shrink. Check the stud size and palm width suit the terminal before ordering.
What's in the box
5 x HellermannTyton CL95-10BM bellmouth copper cable lug
Dimensions
Length
60 mm
Palm width
25 mm
Barrel OD
17.4 mm
Palm thickness
4 mm
Warranty
Manufacturer's warranty
Applications
4WD
RV's
Caravans
Marine
Off-Grid Systems
Tiny Houses
About HellermannTyton
HellermannTyton designs and manufactures products to fasten, connect, protect and identify cables, including cable ties, copper lugs and links, pre-insulated terminals, bootlace ferrules and cable glands. Its terminals and lugs are made to suit HellermannTyton crimping tools for consistent, reliable terminations.
Match two things: the cable size in mm² (for example 16mm² or 50mm²) and the stud or bolt size it fits over (for example M8). The cable size must match the lug barrel exactly so the crimp grips every strand, and the stud size should match your terminal so the lug sits flat and tight.
A bellmouth lug has a flared, funnel-shaped barrel entry. It makes it easy to insert fine-stranded flexible cable, which tends to splay after stripping, without strands catching outside the barrel. A standard (straight barrel) lug has a plain entry and suits regular stranded cable.
Use a lug crimper sized for the cable, such as a hexagonal or indent crimping tool. Hex crimpers give an even, all-round compression that suits tinned copper lugs. Hammer crimpers and pliers give inconsistent crimps that can heat up under high current.
Tin plating protects the copper from oxidation and corrosion, keeping a low-resistance connection over time. It is especially useful in damp, salty or high-humidity environments such as caravans, boats and outdoor battery boxes.
