5kW Genesis Inverter | |
Output Data | |
Rated AC Power Output | 5000VA |
Maximum AC Power Output | 5000VA |
AC Output Voltage (Nominal) | 220/230V AC |
AC Output Voltage Range | 184-264.5V AC |
AC Frequency (Nominal) | 50/60 ± 5 |
Maximum Continuous Output Current | 23A |
Total Harmonic Distortion (THD) | < 3% |
Power Factor | 1, adjustable -0.8 to 0.8 |
Utility Monitoring, Islanding Protection, Configurable Power Factor, Country Configurable Thresholds | Yes |
Short Circuit Current from the PV Array | 23A |
Input Data | |
Maximum DC Power | 7750W |
Transformer-less, Ungrounded | Yes |
Maximum Input Voltage | 480V DC |
Nominal DC Input Voltage | 380V DC |
Maximum Input Current | 13.5A DC |
Reverse-Polarity Protection | Yes |
Ground-Fault Isolation Detection | 600kΩ Sensitivity per Unit |
Maximum Inverter Efficiency | 99.2% |
Nighttime Power Consumption | < 2.5W |
Additional Features | |
Supported Communication Interfaces | RS485, Ethernet, Wi-Fi (optional) |
Smart Energy Management | Export Limitation |
Arc Fault Protection | Integrated, User Configurable (According to UL1699B) |
Inverter Commissioning | Within the SetApp mobile application using built-in Wi-Fi Access-Point for local connection |
Installation Specifications | |
AC Output Conduit Size / Wire cross-section | 25mm Maximum / 1-13 mm2 |
DC Input Conduit Size / # of Strings / Wire cross-section | 25mm Maximum / 1-2 strings / 1-13 mm2 |
Dimensions | 450 x 370 x 174mm |
Weight | 11.4kg |
Noise | < 25 dBA |
Cooling | Natural Convection |
Operating Temperature Range | -40ºC to +60ºC |
Protection Rating | IP65 — Outdoor and Indoor |
Standard Compliance | |
Safety | IEC62109, AS/NZS3100 |
Grid Connection Standards | AS/NZS4777:2015 |
Emissions | IEC61000-6-2, IEC61000-6-3, IEC61000-3-11, IEC61000-3-12, FCC Part 15 Class B |
