- Invicta Xero 12V 300Ah LiFePO4 Battery (Bluetooth)
Invicta Xero 12V 300Ah LiFePO4 Battery (Bluetooth)
https://www.powerproductsdirect.com.au/shop/snlx12v300bt-invicta-xero-12v-300ah-lifepo4-battery-bluetooth-17749 https://www.powerproductsdirect.com.au/web/image/product.template/17749/image_1920?unique=3ee62f0Invicta Xero 12V 300Ah LiFePO4 Battery (Bluetooth)
Features
- 300 Ah
- 12 V battery
- Lithium-ion phosphate
- Built-in Bluetooth
- >3,000 charge cycles @ 100% DOD
- Integrated BMS
- IEC62619 certified battery
- IP67 rated
- Water-resistant case with self-venting port
- CANbus communication
- Can be wired in series or parallel
- Fast recharge
- Flat discharge curve offering longer run time
- Extremely low self-discharge rate
Where to use it
The Invicta Xero 12V range has been specifically designed for the replacement of similar-sized lead-acid batteries. The Xero range uses all the benefits of Lithium Iron Phosphate (LiFePO4) technology and pushes the limits in communication possibilities, power, safety and security with its advanced battery technology.
Dimensions
Length | 500 mm |
Width | 265 mm |
Height | 236 mm |
Weight | 36.5 kg |
Safety features and certifications
- IEC62619 certification
- IP67 rated
Warranty
- 7-year full replacement warranty
Applications
4WD
RV's
Caravans
Marine
Off-Grid Systems
Tiny Houses
About Invicta Lithium
Invicta is a quality lithium battery brand operated by Sealed Performance Batteries (SPB), a company with over 25 years in the energy storage industry with a highly technical team specialising in energy storage and power distribution. It was born out of a desire to provide the Australian market with a high-quality Lithium Iron Phosphate (LiFePO4) battery that could easily replace standard SLA sizes and be relied upon by its users today, tomorrow and for many years to come.
This would require components that would meet only the highest standards and rely on SPB’s understanding and experience of the energy storage industry. In particular, the knowledge of Ryan Hammond, SPB’s Technical Director, a qualified engineer with over 18 years of specialised experience in electrical engineering and power distribution. This has resulted in a lithium battery that has thoroughly examined every detail and is proven to deliver a solution of paramount quality and safety. Whether outback, offshore or in need of reliable energy in commercial and industrial applications, our customers know that Invicta will be there for years to come.
Specifications
| Brand | Invicta |
| Tags | |
|---|---|
| Tags |
|
Product Specifications
| Nominal Voltage | 12.8 V |
| Nominal Capacity (250C, 0.33C) | 300 Ah |
| Terminal | M8 |
| Length | 500 mm |
| Width | 265 mm |
| Height | 236 mm (252 mm with terminals) |
| Weight | 36.5 kg |
| Max Charge Voltage | 14.5 ± 0.1 V |
| Standby | 13.8 ± 0.1 V |
| Cut off Voltage | 11 V |
| Max. Discharge Current | 300 A |
| Max. Pulse Discharge Current (3 Sec) | 1000 A |
| Max. Charge Current | 300 A |
| IP Rating | 67 |
| Cycle Life (100% DoD) | > 3000 |
| Operating Temp - Charge | 0 - 600C |
| Operating Temp - Discharge | -20 - 550C |
| Short Circuit Release | Load Release |
| Max. Series / Parallel Configuration | 4S / 16P / 4S+4P |
| Certification | IEC62619 |
