Victron Argodiode 160-2AC 2 Batteries 160A

Victron Argodiode 160-2AC 2 Batteries 160A

This combination does not exist.

$ 162.55 - Inc GST 162.55 in stock AUD $ 162.55

Features:
• Allows Simultaneous Charging of Two Batteries from One Alternator
• 160Amp
• Suits 12V & 24V Systems

Rating :

(0.0)

ADD TO CART Buy now

BrisbaneOnline Only

SKU: ARG160201020

Category: BATTERIES , Cable & Accessories , MONITORING

Features

Diode battery isolator for 2 batteries, 160 A
Low-loss Schottky diodes (about 0.3V at low current, 0.45V at rated output)
Compensation diode to raise alternator output and offset the drop
Alternator energize input for alternators that need voltage on B+
12V and 24V systems
M8 studs connections

Where to use it

A battery isolator lets one alternator charge separate batteries (for example start and house) in boats, vehicles and motorhomes, while stopping one battery from draining the other.

For lithium house batteries or smart alternators, an Orion-Tr Smart DC-DC charger is usually the better choice.

Dimensions

Height	60 mm
Width	120 mm
Depth	150 mm
Weight	1.1 kg

Warranty

5-year warranty
Access to Springers Solar's warranty support team
Authorised Victron dealer

Datasheet_Argodiode-Battery-Isolators-EN-.pdf

Download

Manual_Argo-Diode-Battery-Isolator-80-2SC-EN-NL-FR-DE-IT-ES-SE.pdf

Download

Product Specifications

Maximum charge current (A)	160
Maximum alternator current (A)	160
Number of batteries	2
Nominal battery voltage	12V and 24V
Alternator Energize Input	Yes
Connection	M8 Studs
Compensation diode and Energise connection	6.3 mm Faston
Weight	1.1kg
Dimensions	60 x 120 x 150mm
