Max. Output Current
| 100 A |
Output Voltage | 12 V DC Nominal |
Charger DC Output - House Battery (CH1)
|
|
Output Voltage Range (Bulk)
| 13.8 - 14.8 V DC |
Output Voltage Range (Float)
| 13.0 - 13.8 V DC |
Charger Output Current
| 10 - 100 A (Selectable) |
Output Voltage Range (Equalise - Flooded Battery Only)
| 15.5 V DC |
Equalise Charging Current
| 10% of BULK current setting |
Charging Control
| 4 stages: Test/Bulk/Absorption/Float |
DC Output Bank
| One |
Selectable Battery Type
| Gel, AGM, Lithium, Program, and Flooded batteries (with equalisation for Flooded batteries) |
Current Draw From House Battery (CH1) with Unit ON
| < 600 mA |
Current Draw From House Battery (CH1) with Unit OFF (Standby)
| < 1 mA |
Minimum Operation Voltage House Battery (CH1)
| 8.0 Vdc |
Efficiency
| > 95% |
DC Input (PV Solar Input) - (CH2) | |
DC Input Voltage Range Solar (CH2) | 14.5 - 55 V DC / 80 A max |
DC Input Power Range Solar (CH2) | 1200 W max for 12 V panels, 2000 W max for 24 V panels (max voltage 55 V) |
DC Input Nominal Operation | 17.5 V DC for 12 V PV panels in parallel, 35.0 V DC for 12 V panels in series |
MPPT Tracking Efficiency | > 98% |
DC Input (Start Battery/Alternator (CH3) | |
Input Voltage Range | 10.5 - 16 V DC / 135 A max |
Vehicle Input Startup Voltage when COM1 (12 V Ignition Sense) is connected | 11.7 - 12.6 V DC |
Vehicle Input Startup Voltage when COM1 (12V Ignition Sense) is NOT connected | > 12.7 V DC |
Engine Start Control ON | Start battery/alternator |
Engine Start Control OFF | PV input |
Maximum Input Current | 100 A |
Remote Display Panel | |
Digital Display | Backlit LED display |
Display | Voltage, Current, Status, Error |
Remote Display Dimensions | 100 x 100 mm |
Weight | 0.4 kg |
Communication | CANBUS |
Protection and Features | |
Charger Overall Dimensions | 356 x 205 x 97 mm |
Weight | 3.23 kg |
Storage Range | -40°C to 70°C |
Optimal Operating Range | -20°C to 40°C |
Ingress Protection | IP32 (for mounting in cool, dry locations) |
DC Output Protection | Reverse Battery, Short Circuit, Over Charge, Over Temperature |
Cooling | Forced air ventilation |
Battery Temperature Sensor Port | RJ12 (optional) |
Digital Display Port | RJ12 |
Warranty | 5 years |
